Elbow Shaped Quick Connect Air Fittings Utah Pneumatic Fittings are a compact one piece push-to-connect fitting.

  • $14.90
  • Save $7.10


Style:Straight

Utah Pneumatic Fittings are a compact one piece push-to-connect fitting.
All items in the Utah Pneumatic composite range are silicone free.
The Stainless steel gripping ring ensures excellent tube retention while the D seal
within the fitting provides a positive seal on the O.D. of the tube,
in both static and dynamic positions, due to an optimized design of the fitting cavity.
Utah Pneumatic composite should not be used for live swivel applications.
Body and collar are made of Nylon 6.6, gripping ring is stainless steel, and D seal and O-rings are Nitrile.

  • Type:Push in fitting/Push to connect Union/Straight
  • Weight:4.8g/Size:8mm Fluid Admitted:Air Vacuum Water (no freezing)
  • Working Pressure:0-1.0MPa | 0-150psi/Applicable Tube:PU / PA / PE / PVC
  • Proof Pressure:3.0Mpa | 435psi.Seal O-ring:NBR/ Lock Claw:Stainless Steel(SUS)/Body:Plastic(PET)
  • Working Temperature:0-60°C | 32~140°F/Negative Pressure:-100Kpa | -29.5 In Hg
